Yealink A10-010 Teams Collab bar + VCR11 1203680
Video bar · Microsoft Teams
Add this product to your quote list and send us your request. We'll be in touch with options, availability and pricing for your configuration.
Questions about this product? or chat on WhatsApp.
Specifications
Performance
- Number of cameras
- 1
- Bluetooth
- Yes
- Bluetooth version
- 4.2
- Product colour
- Black, Grey
- Auto framing
- Yes
- Auto-tracking
- Yes
- Tracking modes
- Presenter mode
- Meeting features
- Add participates, Calendar, Content sharing, Hold/Resume, One-click join
- Product type
- Video collaboration bar
- Wall mountable
- Yes
- PTZ control
- Yes
Video
- HD type
- 4K Ultra HD
- Maximum video resolution
- 3840 x 2160 pixels
- Maximum frame rate
- 30 fps
- Video codecs
- H.264 High profile, H.264 SVC, H.264
Audio
- Built-in speaker(s)
- Yes
- Audio system full duplex
- Yes
- Echo cancellation
- Yes
- Speaker power
- 5 W
Ports & interfaces
- HDMI output ports quantity
- 1
- USB connector type
- USB Type-A, USB Type-C
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
- 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
- 1
- Ethernet LAN (RJ-45) ports
- 1
- DC-in jack
- Yes
- Line-in
- Yes
- Line-out
- Yes
- Microphone in
- Yes
- Reset slot
- Yes
Network
- Ethernet LAN
- Yes
- Ethernet LAN data rates
- 10,100,1000 Mbit/s
- Wi-Fi
- Yes
- Security algorithms
- 256-bit AES, EAP-TLS, MSCHAPv2, PEAP, TLS
Camera
- Camera type
- Single camera
- Horizontal field of view
- 105°
- Diagonal field of view
- 120°
- Auto Focus (AF) object detection
- People
- Remote control interface
- Ethernet
- Camera privacy shutter
- Yes
Microphone
- Microphone sensitivity
- 88 dB
- Microphone mute
- Yes
- Number of microphone arrays
- 8
Features
- Motion sensor
- Yes
- Cable lock slot
- Yes
Logistics data
- Country of origin
- China
Computer system
- Operating system installed
- Android 10
- Mobile operating systems supported
- Android 11.0
Operational conditions
- Operating temperature (T-T)
- 0 - 40 °C
- Operating relative humidity (H-H)
- 10 - 95%
- Storage temperature (T-T)
- -30 - 70 °C
Power
- Power source type
- AC
- AC input voltage
- 100 - 240 V
- DC output voltage
- 48 V
- DC output current
- 0.7 A
- Power consumption (typical)
- 10.5 W
- Power consumption (max)
- 14 W
- Power consumption (idle)
- 10 W
Certificates
- Certification
- CE, FCC, RoHS, REACH, ISO 9001, CCC, NOM
Weight & dimensions
- Width
- 380 mm
- Depth
- 68 mm
- Height
- 82 mm
- Weight
- 2.08 kg
Packaging data
- Package width
- 165 mm
- Package depth
- 150 mm
- Package height
- 447 mm
- Package weight
- 2.31 kg
Packaging content
- Cables included
- HDMI, LAN (RJ-45)
- Networking cable length
- 3 m
- HDMI cable length
- 1.8 m
- AC adapter included
- Yes
- Remote control included
- Yes
- Quick start guide
- Yes
About the Yealink A10-010 Teams Collab bar + VCR11
The Yealink A10-010 Teams Collab bar + VCR11 is a video collaboration bar in black and grey with 1 camera. Its HD type is 4K Ultra HD, its maximum video resolution is 3840 x 2160 pixels, and its maximum frame rate is 30 fps. It has auto framing, auto-tracking and a camera privacy shutter, its horizontal field of view is 105°, and its diagonal field of view is 120°. It has a built-in speaker with a speaker power of 5 W, Bluetooth, Wi-Fi and Ethernet LAN.
Frequently asked questions
Have another question?
How much does the Yealink A10-010 Teams Collab bar + VCR11 cost in Singapore?
How do you confirm availability for this SKU?
What warranty comes with the A10-010 Teams Collab bar + VCR11?
Can you install the A10-010 Teams Collab bar + VCR11?
What if the wrong configuration is ordered?
