9103-73784Eaton 9PX 1000i RT2U 9103-53748
1,000 VA · Online double-conversion · Tower/Rack convertible
Part number9103-53748
SRP S$2,626.90
Indicative only — contact us for accurate pricing. Questions about this product? or chat on WhatsApp.
Specifications
Features
- UPS topology
- Double-conversion (Online)
- Output power capacity
- 1 kVA
- Output power
- 1000 W
- Waveform
- Pure sine
- Input operation voltage (min)
- 176 V
- Input operation voltage (max)
- 276 V
- Input frequency
- 40/70 Hz
- Output operation voltage (min)
- 200 V
- Output operation voltage (max)
- 240 V
- Output frequency
- 50/60 Hz
- Number of input phases
- 1
- Efficiency
- 91.5%
- Power factor
- 1
- Noise level
- 35 dB
- Power protection features
- Battery discharge
Ports & interfaces
- AC outlet types
- C13 coupler
- Power plug
- C14 coupler
- AC outlets quantity
- 8 AC outlet(s)
- USB port
- Yes
- USB 2.0 ports quantity
- 1
- Serial interface
- Yes
- Serial interface type
- RS-232
- RS-232 ports
- 1
Battery
- Battery technology
- Sealed Lead Acid (VRLA)
- Typical backup time at full load
- 6 min
- Typical backup time at half load
- 16.5 min
- Hot-swap battery
- Yes
- Automatic battery test
- Yes
Design
- Form factor
- Rackmount/Tower
- Rack capacity
- 2U
- Product colour
- Black
- Display type
- LCD
- LED indicators
- Yes
Operational conditions
- Operating temperature (T-T)
- 0 - 40 °C
Certificates
- Certification
- IEC/EN 62040-1, UL 1778, CSA 22.2, IEC/EN 62040 -2, FCC Class B, CISPR22 Class B, CE /CB report (TUV) / cULus / EAC /RCM / KC / Energy Star
Packaging content
- Rack mount kit
- Yes
- Management card included
- No
Safety regulation & standards
- Safety
- IEC/EN 62040-1, UL 1778, CSA 22.2
Sustainability
- Sustainability certificates
- ENERGY STAR
Weight & dimensions
- Width
- 440 mm
- Depth
- 450 mm
- Height
- 86.5 mm
- Weight
- 19.5 kg
Packaging data
- Bundled software
- Intelligent Power Software suite
Logistics data
- Harmonized System (HS) code
- 85078000
Other features
- Nominal input voltage
- 230 V
About the Eaton 9PX 1000i RT2U
1000 VA / 1000 W online UPS (rackmount/tower) with 8 AC outlets. Battery technology: Sealed Lead Acid (VRLA); AC outlet types: C13 coupler; typical backup time at half load: 16.5 min.
