APC NetShelter Rack PDU Advanced, Metered, 34.6kW, 3PH, 415V, 60A, 560P6 APDU11450ME
Rackmount
Part numberAPDU11450ME
Price on request
Order on request Questions about this product? or chat on WhatsApp.
Highlights
- AC outlets quantity: 42 AC outlet(s)
- AC outlet types: C13 coupler, C15 coupler, C19 coupler, C21 coupler
- Ethernet LAN (RJ-45) ports: 5
- USB ports quantity: 1
- Input connection type: IEC 60309 60 A 3P + N + PE
Specifications
Ports & interfaces
- AC outlets quantity
- 42 AC outlet(s)
- AC outlet types
- C13 coupler, C15 coupler, C19 coupler, C21 coupler
- Ethernet LAN (RJ-45) ports
- 5
- USB ports quantity
- 1
- Input connection type
- IEC 60309 60 A 3P + N + PE
Design
- PDU types
- Metered
- Type
- Three-phase
- Rack capacity
- 0U
- Product colour
- Black
Features
- Cable length
- 3 m
Power
- Nominal input voltage
- 415 3 phases
- AC input frequency
- 50/60 Hz
- Maximum current
- 60 A
- Nominal output voltage
- 400 V
- Output voltage
- 240 V
- Load capacity
- 34600 VA
- Number of phases
- 3
- Battery replacement accessibility
- Non-removable
Weight & dimensions
- Width
- 56 mm
- Depth
- 75 mm
- Height
- 1826 mm
- Weight
- 11.7 kg
Management features
- Management platform
- NMC3
Certificates
- Waste Electrical and Electronic Equipment (WEEE) compliance
- Yes
- Compliance certificates
- RoHS, REACH, WEEE
Packaging data
- Package weight
- 17 kg
- Package width
- 132 mm
- Package depth
- 262 mm
- Package height
- 2110 mm
About the APC NetShelter Rack PDU Advanced, Metered, 34.6kW, 3PH, 415V, 60A, 560P6
APC NetShelter Rack PDU Advanced Gen 2, Metered, 3Phase, 43.5kW 400V 63A or 34.6kW 415V 60A, 560P6, 42 Outlet, Metered, 0U, Three-phase, Black, 42 AC outlet(s), C13 coupler, C15 coupler, C19 coupler, C21 coupler
